ATB06
Maximum pulling force: 6.5KN
Maximum pulling capacity: 6000KG
TDER Electric Tow Tractor features a high-efficiency electric drive system with outstanding advantages such as zero emissions, low noise, and minimal maintenance. It is particularly suitable for areas with strict environmental and noise regulations, including airport terminals, high-speed railway platforms, and warehouse workshops.
With a compact body and agile handling, it ensures smooth operation in narrow aisles, frequent start-stop conditions, and multi-operator working scenarios. Combined with a high-capacity battery and precise electronic control system, it significantly enhances endurance and operational efficiency, making it an ideal solution for green towing and transport tasks.
1. Multi-Trailer Towing Capability:Maximum towing force reaches 6,500 N with a rated load of 6,000 kg, allowing multiple baggage trailers to be towed efficiently—ideal for daily airport transfer tasks.
2. High-Capacity Battery for Extended Operation:Equipped with a DIN-standard 48V/275Ah battery pack, providing long-lasting performance and reducing the need for frequent charging, thus improving operational efficiency.
3. Precise Speed Control with Energy Regeneration:Responsive speed control system supports regenerative braking, effectively reducing energy consumption and enhancing overall operating economy.
4. Compact Body Design for Confined Spaces:With a minimum turning radius of only 1,850 mm, the compact structure allows agile maneuvering around gates, cargo holds, and underground transfer passages.
5. Solid Tires for Stability and Zero Maintenance:Standard 4.00-8 high-strength solid tires are wear-resistant and puncture-proof, eliminating inflation needs and adapting well to all types of airport surfaces.
6. Low Center of Gravity for Enhanced Safety:Optimized chassis and center-of-gravity layout ensure driving stability and safety during towing, especially in fast dispatch scenarios with multiple trailers attached.
Model | ATB06 | |
Power Type | Electric | |
Rated Load | kg | 6000 |
Maximum Traction | N | 6500 |
Rated Traction | N | 1600 |
Maximum Travel Speed (Loaded) | km/h | 9.5 |
Maximum Travel Speed (Unloaded) | km/h | 10.5 |
Overall Length | mm | 1966 |
Overall Width | mm | 1010 |
Overall Height | mm | 1300 |
Wheelbase | mm | 1100 |
Minimum Turning Radius | mm | 1850 |
Rear Wheelbase | mm | 820 |
Minimum Ground Clearance | mm | 60 |
Tire Types | Solid Tires | |
Front Tire Size | 4.00-8 | |
Rear Axle Tire Size | 4.00-8 | |
Empty Vehicle Weight (No Load) | kg | 1150 |
Drive Motors | kW | 6 |
Battery Type | DIN | |
Battery Capacity | V/AH | 48/275 |
Battery Weight | kg | 540 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
