TDER B Series Diesel Forklift, as TDER's basic model, covers a wide range of capacities from 1.5 to 10 tons.This series continues TDER's commitment to high-quality manufacturing standards, offering excellent durability and reliability, especially in outdoor environments and medium to heavy-duty working conditions. They are widely used in industrial manufacturing, construction, port logistics, warehousing, and transportation.
The B-Series Diesel Forklifts combine versatility and cost-effectiveness, with stable power output and easy maintenance, resulting in a short return on investment period. They are the ideal choice for dealers and end-users alike. As one of TDER's trusted classic products, the B-Series not only demonstrates precise control over practical performance but also showcases TDER's professional expertise in continuous development and innovation in the industrial vehicle sector.
1.Comfortable and Convenient Operation: The control system is designed based on ergonomic principles, fitting human operating habits, greatly improving operational comfort. It is equipped with drum brakes and a fully hydraulic power brake system, offering easy operation and quick response, making the driving experience more relaxed and safe.
2.Wide and Clear Visibility: The wide-view mast design significantly reduces blind spots, providing a more comprehensive view during operation, effectively improving operational accuracy and safety, and helping to avoid accidental collisions.
3.Precise Control of Machine Status: Equipped with a reliable LCD digital instrument, offering a user-friendly interface. The status of all vehicle functions is displayed clearly in real time, making it easy for the driver to quickly and accurately grasp the information, thus improving work efficiency.
4.Reliable Power System: Powered by a high-performance Xichai engine, offering strong, abundant, and stable power. The reliable transmission system is matched with a new power-assist device, improving transmission efficiency, reducing the likelihood of failure, and ensuring reliable performance.
5.Optimized Air Intake System: The high intake system design keeps the engine away from dust, reducing wear. The intake, exhaust, and cooling systems are optimized to extend the engine's lifespan and enhance the overall durability of the machine.
6.Reasonable Structural Design: The shorter front overhang design effectively reduces the load on the front axle in a fully loaded state, significantly improving the lifespan of the front tires and the drive axle.
7.High-Quality and Durable Configuration: Equipped with durable core components, such as the Linde drive axle, and advanced manufacturing processes combined with high-quality parts, ensuring high vehicle reliability, long-lasting durability, and reduced maintenance frequency.
| Model |
| FD80 |
| Rated lifting capacity | kg | 8000 |
| Load center distance | mm | 600 |
| Free lifting height | mm | 200 |
| Overall length (with/without forks) | mm | 5175/3955 |
| Width (mm) | mm | 2245 |
| Height of top shroud | mm | 2570 |
| Wheelbase | mm | 2800 |
| Minimum Ground Clearance | mm | 250 |
| Mast tilt angle (front/rear) | ° | 10/12 |
| Front Tire Size |
| 9.00-20NHS |
| Rear Tire Size |
| 9.00-20NHS |
| Minimum Turning Radius (Outside) | mm | 3755 |
| Minimum Right Angle Passage Width | mm | 5755 |
| Fork size | mm | 1520*170*70 |
| Maximum working speed (full/no load) | km/h | 20/26 |
| Max. lifting speed (full/no load) | mm/s | 330/350 |
| Maximum gradient (full/no load) | % | 15/20 |
| Forklift weight | kg | 11800 |
| Engine Brand |
| Xichai |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
