Heavy Duty Forklift
15 Tonne Diesel Forklift Truck


FD150


Rated Capacity: 15000kg


Lift Height: 4000mm


PRODUCT DETAILS

1.Reliable structure design, through finite element analysis, kinematics, dynamics simulation calculation and harsh fatigue, vibration and other tests, to ensure that the structure of the whole forklift is reliable and durable;

2.The gearbox adopts a variety of control programs integrated into an integrated control component, which can easily realize various control operations, and has a fault diagnosis instrument, which greatly simplifies maintenance and maintenance;

3.The gantry is sturdy and durable, and has a good vision;the fork adopts a rolling structure to reduce the resistance of the cargo side shifting distance adjustment.


Model
FD150
Power Type
Diesel
Rated Capacitykg15000
Load Centremm600
Lift Heightmm3000
Mast Tilt AngleF/RDeg8°/12°
Ground Clearance(Bottom of mast)mm250
Overall Widthmm2550
Mast Lowered Heightmm3240
Turning Radius (outside)mm5400
Speed Travel (Full load)km/h28
TireFrontmm4*12.00-24*18PR
Rearmm2*10.00-20*16PR
Wheelbasemm3200
Battery Voltage/CapacityV/Ah(12/80) x 2
EngineModel
YC6B125-T11
Manufacture
YUCHAI
Rated output/r.p.m.kw92/2300
Rated torque/r.p.m.N·m450/1300
No.of Cylinder
6
Bore×Strokemm107×124
Displacementcc6871
Fuel Tank CapacityL300


With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.
