Heavy Duty Forklift
16T Diesel Forklift Truck


FD160


Rated Capacity: 16000kg


Lift Height: 4000mm


PRODUCT DETAILS

1.Reliable structure design, through finite element analysis, kinematics, dynamics simulation calculation and harsh fatigue, vibration and other tests, to ensure that the structure of the whole forklift is reliable and durable;

2.The gearbox adopts a variety of control programs integrated into an integrated control component, which can easily realize various control operations, and has a fault diagnosis instrument, which greatly simplifies maintenance and maintenance;

3.The gantry is sturdy and durable, and has a good vision;the fork adopts a rolling structure to reduce the resistance of the cargo side shifting distance adjustment.


Model
FD160
Power Type
Diesel
Rated Capacitykg16000
Load Centremm900
Lift Heightmm4000
Mast Tilt AngleF/RDeg6°/12°
Front Overhang (Wheel center to fork face)mm900
Ground Clearance(Bottom of mast)mm250
Length to face of fork(Without fork)mm5430
Overall Widthmm2610
Mast Lowered Heightmm3660
Turning Radius (outside)mm5300
Speed Travel (Full load)km/h37
TireFrontmm12.00-24-24PR
Rearmm12.00-20-20PR
Wheelbasemm3600
Battery Voltage/CapacityV/Ah24/240
EngineModel
CUMMINS
Manufacture
QSB6.7
Rated output/r.p.m.kw129/2200
Rated torque/r.p.m.N·m800/1500
No.of Cylinder
6
Bore×Strokemm107×124
Displacementcc6700
Fuel Tank CapacityL350


With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.
