FG40
Rated Load:4000kg
Lifting Height:3000mm
TDER LPG/Gasoline Forklift combines the structural strength of diesel models with cleaner, quieter LPG power. Equipped with the GCT K25 engine, it delivers stable performance and lower emissions, making it ideal for indoor or semi-enclosed environments.
The robust vehicle structure features a wide-view mast and an integrated cast steering axle for reliable durability. The hydraulic system employs tapered seals and filtered oil to extend service life, while the electrical system's rational wiring facilitates easier maintenance. Operational design prioritizes ergonomics, offering comfortable handling with low step height and ample space. Smart features include digital instrumentation, USB charging, and fault alerts. The TDER LPG/Gasoline Forklift represents an ideal choice balancing efficiency and environmental responsibility.
1. Powerful and Efficient Engine:Equipped with the Japanese Nissan K25 or US PSI 2.4 EPA dual-fuel engine, delivering strong power and excellent fuel efficiency, meeting both environmental and high-performance operation requirements.
2. Reliable Transmission and Drive Axle:Featuring Zhongchai or Zhongnan electro-hydraulic transmission and Linde drive axle, ensuring smooth shifting, efficient power delivery, and stable performance under heavy-duty and high-intensity conditions.
3. Durable Chassis Structure:Standard composite counterweight, with optional cast iron counterweight, providing a lower center of gravity and ensuring long-lasting stability under high-load continuous operation.
4. Versatile Tire Options:Standard solid tires for puncture resistance and low maintenance, with optional Chaoyang pneumatic tires to enhance driving comfort and adaptability on complex surfaces.
5. Comfortable and Safe Operation:Ergonomic Toyota seat combined with a clear LCD display, backup alarm, warning lights, and LED lamps, providing operators with intuitive, comfortable, and safe handling experience.
Model | FG40 | |
Rated lifting load | kg | 4000 |
Load center distance | mm | 500 |
Lifting height | mm | 3000 |
Free lifting height | mm | 100 |
Overall length (With / Without fork) | mm | 4990/2960 |
Width | mm | 1225 |
Overhead guard height | mm | 2165 |
Wheelbase | mm | 1850 |
Minimum ground clearance | mm | 140 |
Mast tilt angle (front/rear) | % | 6° /12° |
Minimum turning radius (outer side) | mm | 2650 |
Minimum right angle aisle width | mm | 4750 |
Fork size | mm | 1220*125*50 |
Maximum working speed(load/unload) | km/h | 19/19 |
Maximum lifting speed(load/unload) | mm/s | 480/520 |
Maximum gradeability(load/unload) | % | 15/20 |
Forklift weight | kg | 4250 |
Engine model | GCT-K25 | |
Transmission | Electro-Hydraulic | |
Tire Brand | Advance | |
Tire no. (before) | 28x9-15-12PR | |
Tire no. (after) | 6.50-10-10PR |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
