PRODUCT DETAILS

Model	ERF15R
Capacity	kg	1500
Load center	mm	600
Front overhang	mm	384
Wheelbase	mm	1913
Total weight including the battery	kg	9300
Wheel type	Pu solid tire
Front wheel	mm	φ350*200
Driving wheel	mm	φ400*160
Wheel tread:Front	mm	1190
Mast height(fork lowering)	mm	4480
Free lift height	mm	1500
Max lifting height	mm	7500
Max.height	mm	8400
Overhead guard height	mm	2412
Fork height when gantry retracted	mm	45
Total length	mm	3679
Overall length	mm	2448
Overall width	mm	1474
Fork dimension	mm	451251220
Auxiliary wheel width	mm	1609
Min ground clearance	mm	80
Driving motor	kw	8
Lifting motor	kw	12
Battery type	Lead acid battery
Battery capacity	V/Ah	48V530Ah
Charger-Intelligent	V/Ah	48V/75A
Drive control method	AC

With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.
